Models & Specifications

Specs as rows · Models as columns

Specifications	NR22Y-L1-4	NR22Y-L1-5	NR22Y-L2-16	NR22Y-L2-20	NR22Y-L2-25	NR22Y-L3-64	NR22Y-L3-100	NR22Y-L3-125	NR22Y-L3-140
Rated output torque	2 N·m	2 N·m	2 N·m	2 N·m	2 N·m	2 N·m	2 N·m	2 N·m	2 N·m
Reduction Ratio	4	5	16	20	25	64	100	125	140
Efficiency	92%	92%	84%	84%	84%	77%	77%	77%	77%
Stage	1	1	2	2	2	3	3	3	3
Backlash	12arcmin	12arcmin	18arcmin	18arcmin	18arcmin	25arcmin	25arcmin	25arcmin	25arcmin
Protection Level	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54
Moment of inertia	0.144kg·cm²	0.145kg·cm²	0.0716kg·cm²	0.072kg·cm²	0.072kg·cm²	0.0364kg·cm²	0.031kg·cm²	0.03125kg·cm²	0.0314kg·cm²

* Scroll horizontally within the table area when the content is wide.

Specifications

Rated Input Speed	5000 rpm
Max Input Speed	10000 rpm
Max Radial Load	50 N
Max Axial Load	20 N
Noise	54 dB
Average Lifespan	8000 h
Standard Tolerance	- %
Lubricating	Synthetic oil lubrication
Weight	- kg
