Models & Specifications

Specs as rows · Models as columns

Specifications	NR28Y-L1-4	NR28Y-L1-5	NR28Y-L1-7	NR28Y-L1-10	NR28Y-L2-16	NR28Y-L2-20	NR28Y-L2-25	NR28Y-L2-28	NR28Y-L2-35	NR28Y-L2-40	NR28Y-L2-50	NR28Y-L3-64	NR28Y-L2-70	NR28Y-L3-80	NR28Y-L3-100	NR28Y-L3-125	NR28Y-L3-140	NR28Y-L3-175	NR28Y-L3-200
Rated output torque	2 N·m	2 N·m	2 N·m	1 N·m	4 N·m	4 N·m	4 N·m	4 N·m	4 N·m	3 N·m	3 N·m	6 N·m	3 N·m	6 N·m	6 N·m	6 N·m	6 N·m	6 N·m	6 N·m
Reduction Ratio	4	5	7	10	16	20	25	28	35	40	50	64	70	80	100	125	140	175	200
Efficiency	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%
Stage	1	1	1	1	2	2	2	2	2	2	2	3	2	3	3	3	3	3	3
Backlash	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin
Protection Level	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54
Moment of inertia	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²

* Scroll horizontally within the table area when the content is wide.

Specifications

Rated Input Speed	1000 rpm
Max Input Speed	2000 rpm
Max Radial Load	300 N
Max Axial Load	100 N
Noise	60 dB
Average Lifespan	20000 h
Standard Tolerance	- %
Lubricating	Synthetic oil lubrication
Weight	- kg

Downloads

Name	Type	Size	Update Date	Download
NiMotion Gearbox Selection Guide	Selection Guide	11.8MB	2026-09-07
