Models & Specifications

Specs as rows · Models as columns

Specifications	NPLE040-L1-3	NPLE040-L1-4	NPLE040-L1-5	NPLE040-L1-8	NPLE040-L2-16	NPLE040-L2-20	NPLE040-L2-25	NPLE040-L2-40	NPLE040-L3-64	NPLE040-L3-80	NPLE040-L3-100	NPLE040-L3-120	NPLE040-L3-160	NPLE040-L3-200
Rated output torque	6 N·m	9 N·m	9 N·m	7 N·m	12 N·m	12 N·m	10.5 N·m	10.5 N·m	15.5 N·m	15.5 N·m	15.5 N·m	9 N·m	15.5 N·m	13.5 N·m
Reduction Ratio	3	4	5	8	16	20	25	40	64	80	100	120	160	200
Efficiency	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%
Stage	1	1	1	1	2	2	2	2	3	3	3	3	3	3
Backlash	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin
Protection Level	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54
Moment of inertia	0.03kg·cm²	0.022kg·cm²	0.019kg·cm²	0.017kg·cm²	0.019kg·cm²	0.019kg·cm²	0.017kg·cm²	0.016kg·cm²	0.019kg·cm²	0.019kg·cm²	0.019kg·cm²	0.029kg·cm²	0.016kg·cm²	0.016kg·cm²

* Scroll horizontally within the table area when the content is wide.

Specifications

Rated Input Speed	3000 rpm
Max Input Speed	4500 rpm
Max Radial Load	185 N
Max Axial Load	150 N
Noise	60 dB
Average Lifespan	20000 h
Standard Tolerance	- %
Lubricating	Synthetic oil lubrication
Weight	- kg

Downloads

Name	Type	Size	Update Date	Download
NiMotion Gearbox Selection Guide	Selection Guide	11.8MB	2026-09-07
