Models & Specifications

Specs as rows · Models as columns

Specifications	NPLFK080-L1-3	NPLFK080-L1-4	NPLFK080-L1-5	NPLFK080-L1-7	NPLFK080-L1-10	NPLFK080-L2-12	NPLFK080-L2-15	NPLFK080-L2-16	NPLFK080-L2-20	NPLFK080-L2-25	NPLFK080-L2-28	NPLFK080-L2-35	NPLFK080-L2-40	NPLFK080-L2-50	NPLFK080-L3-64	NPLFK080-L2-70	NPLFK080-L3-80	NPLFK080-L3-100	NPLFK080-L3-125	NPLFK080-L3-140	NPLFK080-L3-160	NPLFK080-L3-175	NPLFK080-L3-200	NPLFK080-L3-250	NPLFK080-L3-280	NPLFK080-L3-350
Rated output torque	60 N·m	86 N·m	94.5 N·m	64 N·m	39.5 N·m	96 N·m	96 N·m	96 N·m	96 N·m	105.5 N·m	96 N·m	105.5 N·m	96 N·m	105.5 N·m	120 N·m	71.5 N·m	120 N·m	120 N·m	132 N·m	120 N·m	120 N·m	132 N·m	120 N·m	132 N·m	120 N·m	132 N·m
Reduction Ratio	3	4	5	7	10	12	15	16	20	25	28	35	40	50	64	70	80	100	125	140	160	175	200	250	280	350
Efficiency	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%
Stage	1	1	1	1	1	2	2	2	2	2	2	2	2	2	3	2	3	3	3	3	3	3	3	3	3	3
Backlash	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin
Protection Level	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54
Moment of inertia	0.4kg·cm²	0.309kg·cm²	0.291kg·cm²	0.285kg·cm²	0.283kg·cm²	0.4kg·cm²	0.4kg·cm²	0.309kg·cm²	0.291kg·cm²	0.285kg·cm²	0.285kg·cm²	0.285kg·cm²	0.283kg·cm²	0.283kg·cm²	0.291kg·cm²	0.283kg·cm²	0.291kg·cm²	0.291kg·cm²	0.285kg·cm²	0.285kg·cm²	0.285kg·cm²	0.285kg·cm²	0.283kg·cm²	0.283kg·cm²	0.283kg·cm²	0.283kg·cm²

* Scroll horizontally within the table area when the content is wide.

Specifications

Rated Input Speed	3000 rpm
Max Input Speed	6000 rpm
Max Radial Load	1420 N
Max Axial Load	1250 N
Noise	65 dB
Average Lifespan	20000 h
Standard Tolerance	- %
Lubricating	Synthetic oil lubrication
Weight	- kg
