Models & Specifications

Specs as rows · Models as columns

Specifications	NR28F-L1-4	NR28F-L1-5	NR28F-L1-7	NR28F-L1-10	NR28F-L2-16	NR28F-L2-20	NR28F-L2-25	NR28F-L2-28	NR28F-L2-35	NR28F-L2-40	NR28F-L2-50	NR28F-L3-64	NR28F-L2-70	NR28F-L3-80	NR28F-L3-100	NR28F-L3-112	NR28F-L3-125	NR28F-L3-140	NR28F-L3-160	NR28F-L3-175	NR28F-L3-200	NR28F-L3-250	NR28F-L3-280	NR28F-L3-350	NR28F-L3-400	NR28F-L3-500	NR28F-L3-700
Rated output torque	9 N·m	8.5 N·m	5 N·m	3 N·m	9 N·m	9 N·m	8.5 N·m	9 N·m	8.5 N·m	9 N·m	8.5 N·m	9 N·m	5 N·m	9 N·m	9 N·m	9 N·m	8.5 N·m	9 N·m	9 N·m	8.5 N·m	9 N·m	8.5 N·m	9 N·m	8.5 N·m	9 N·m	8.5 N·m	5 N·m
Reduction Ratio	4	5	7	10	16	20	25	28	35	40	50	64	70	80	100	112	125	140	160	175	200	250	280	350	400	500	700
Efficiency	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%
Stage	1	1	1	1	2	2	2	2	2	2	2	3	2	3	3	3	3	3	3	3	3	3	3	3	3	3	3
Backlash	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin
Protection Level	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54
Moment of inertia	0.018kg·cm²	0.014kg·cm²	0.012kg·cm²	0.01kg·cm²	0.018kg·cm²	0.014kg·cm²	0.014kg·cm²	0.012kg·cm²	0.012kg·cm²	0.01kg·cm²	0.01kg·cm²	0.018kg·cm²	0.01kg·cm²	0.014kg·cm²	0.014kg·cm²	0.014kg·cm²	0.014kg·cm²	0.014kg·cm²	0.012kg·cm²	0.014kg·cm²	0.01kg·cm²	0.01kg·cm²	0.01kg·cm²	0.01kg·cm²	0.01kg·cm²	0.01kg·cm²	0.01kg·cm²

* Scroll horizontally within the table area when the content is wide.

Specifications

Rated Input Speed	3000 rpm
Max Input Speed	6000 rpm
Max Radial Load	150 N
Max Axial Load	80 N
Noise	60 dB
Average Lifespan	20000 h
Standard Tolerance	- %
Lubricating	Synthetic oil lubrication
Weight	- kg

Downloads

Name	Type	Size	Update Date	Download
NiMotion Gearbox Selection Guide	Selection Guide	11.8MB	2026-09-07
