Models & Specifications

Specs as rows · Models as columns

Specifications	NR42F-L1-3	NR42F-L1-4	NR42F-L1-5	NR42F-L1-7	NR42F-L1-10	NR42F-L2-12	NR42F-L2-15	NR42F-L2-16	NR42F-L2-20	NR42F-L2-25	NR42F-L2-28	NR42F-L2-35	NR42F-L2-40	NR42F-L2-50	NR42F-L3-60	NR42F-L3-64	NR42F-L2-70	NR42F-L3-75	NR42F-L3-80	NR42F-L3-100	NR42F-L3-112	NR42F-L3-125	NR42F-L3-140	NR42F-L3-160	NR42F-L3-175	NR42F-L3-200	NR42F-L3-250	NR42F-L3-280	NR42F-L3-350	NR42F-L3-400	NR42F-L3-500	NR42F-L3-700
Rated output torque	4.5 N·m	15 N·m	14 N·m	8 N·m	5 N·m	18 N·m	18 N·m	20 N·m	20 N·m	18 N·m	20 N·m	18 N·m	20 N·m	18 N·m	18 N·m	20 N·m	10 N·m	18 N·m	20 N·m	20 N·m	20 N·m	18 N·m	20 N·m	20 N·m	18 N·m	20 N·m	18 N·m	20 N·m	18 N·m	20 N·m	18 N·m	10 N·m
Reduction Ratio	3	4	5	7	10	12	15	16	20	25	28	35	40	50	60	64	70	75	80	100	112	125	140	160	175	200	250	280	350	400	500	700
Efficiency	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%	96%
Stage	1	1	1	1	1	2	2	2	2	2	2	2	2	2	3	3	2	3	3	3	3	3	3	3	3	3	3	3	3	3	3	3
Backlash	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin
Protection Level	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54
Moment of inertia	0.031kg·cm²	0.022kg·cm²	0.019kg·cm²	0.017kg·cm²	0.015kg·cm²	0.029kg·cm²	0.023kg·cm²	0.022kg·cm²	0.019kg·cm²	0.019kg·cm²	0.017kg·cm²	0.017kg·cm²	0.015kg·cm²	0.015kg·cm²	0.029kg·cm²	0.022kg·cm²	0.015kg·cm²	0.023kg·cm²	0.019kg·cm²	0.019kg·cm²	0.017kg·cm²	0.019kg·cm²	0.017kg·cm²	0.015kg·cm²	0.017kg·cm²	0.015kg·cm²	0.015kg·cm²	0.015kg·cm²	0.015kg·cm²	0.015kg·cm²	0.015kg·cm²	0.015kg·cm²

* Scroll horizontally within the table area when the content is wide.

Specifications

Rated Input Speed	3000 rpm
Max Input Speed	6000 rpm
Max Radial Load	200 N
Max Axial Load	160 N
Noise	58 dB
Average Lifespan	20000 h
Standard Tolerance	- %
Lubricating	Synthetic oil lubrication
Weight	- kg

Downloads

Name	Type	Size	Update Date	Download
NiMotion Gearbox Selection Guide	Selection Guide	11.8MB	2026-09-07
