Models & Specifications

Specs as rows · Models as columns

Specifications	NR40LF-L1-4	NR40LF-L1-5	NR40LF-L1-7	NR40LF-L1-9	NR40LF-L1-10	NR40LF-L2-16	NR40LF-L2-20	NR40LF-L2-25	NR40LF-L2-28	NR40LF-L2-35	NR40LF-L2-40	NR40LF-L2-50	NR40LF-L2-70
Weight	0.5kg	0.5kg	0.5kg	0.5kg	0.5kg	0.6kg	0.6kg	0.6kg	0.6kg	0.6kg	0.6kg	0.6kg	0.6kg
Flange dimensions	40mm	40mm	40mm	40mm	40mm	40mm	40mm	40mm	40mm	40mm	40mm	40mm	40mm
Rated output torque	13 N·m	15 N·m	12 N·m	9 N·m	9 N·m	13 N·m	15 N·m	13 N·m	13 N·m	15 N·m	13 N·m	15 N·m	12 N·m
Reduction Ratio	4	5	7	9	10	16	20	25	28	35	40	50	70
Efficiency	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%
Stage	1	1	1	1	1	2	2	2	2	2	2	2	2
Backlash	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin
Protection Level	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54
Moment of inertia	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²	-kg·cm²

* Scroll horizontally within the table area when the content is wide.

Specifications

Rated Input Speed	4000 rpm
Max Input Speed	8000 rpm
Max Radial Load	185 N
Max Axial Load	150 N
Noise	60 dB
Average Lifespan	20000 h
Standard Tolerance	- %
Lubricating	Synthetic oil lubrication
