VisualTFT HMI Screen Development Software

User-friendly interface with clean and elegant design Supports image import, screen scaling, text editing, element copying, and other functions Built-in virtual serial screen simulator Supports direct KEIL debugging integration

Product Details

VisualTFT is a powerful serial screen development and debugging software featuring a user-friendly and elegant interface. It supports image import, screen scaling, text editing, element copying, and other common operations. The software includes a built-in virtual serial screen simulator and supports direct KEIL debugging integration.

The IDE offers intuitive operation with a clean and attractive layout. It includes a built-in font generator and Lua script compiler. After creating a new project, users can import pre-designed artwork and configure buttons and controls on each screen. Common operations such as image scaling, text editing, and element copying are fully supported.

Upon project compilation, each screen, image, and control is assigned a unique ID. The embedded virtual serial screen simulator enables direct KEIL debugging, and the built-in command debugger facilitates convenient PC-to-serial screen debugging.

Downloads

Name	Type	Size	Update Date	Download
NiMotion Software Selection Guide	Selection Guide	1.4MB	2026-08-25
