Models & Specifications

Specs as rows · Models as columns

Specifications	NPLF080-L1-3	NPLF080-L1-4	NPLF080-L1-5	NPLF080-L1-7	NPLF080-L1-10	NPLF080-L2-12	NPLF080-L2-15	NPLF080-L2-16	NPLF080-L2-20	NPLF080-L2-25	NPLF080-L2-28	NPLF080-L2-35	NPLF080-L2-40	NPLF080-L2-50	NPLF080-L3-64	NPLF080-L2-70	NPLF080-L3-80	NPLF080-L3-100	NPLF080-L3-140	NPLF080-L3-160	NPLF080-L3-175	NPLF080-L3-200	NPLF080-L3-250	NPLF080-L3-280	NPLF080-L3-350
Rated output torque	60 N·m	86 N·m	94.5 N·m	64 N·m	39.5 N·m	96 N·m	96 N·m	96 N·m	96 N·m	105.5 N·m	96 N·m	105.5 N·m	96 N·m	105.5 N·m	120 N·m	71.5 N·m	120 N·m	120 N·m	120 N·m	120 N·m	132 N·m	120 N·m	132 N·m	120 N·m	132 N·m
Reduction Ratio	3	4	5	7	10	12	15	16	20	25	28	35	40	50	64	70	80	100	140	160	175	200	250	280	350
Efficiency	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%	90%
Stage	1	1	1	1	1	2	2	2	2	2	2	2	2	2	3	2	3	3	3	3	3	3	3	3	3
Backlash	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin	-arcmin
Protection Level	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54	IP54
Moment of inertia	0.4kg·cm²	0.309kg·cm²	0.291kg·cm²	0.285kg·cm²	0.283kg·cm²	0.4kg·cm²	0.4kg·cm²	0.309kg·cm²	0.291kg·cm²	0.285kg·cm²	0.283kg·cm²	0.285kg·cm²	0.283kg·cm²	0.283kg·cm²	0.291kg·cm²	0.283kg·cm²	0.291kg·cm²	0.291kg·cm²	0.291kg·cm²	0.285kg·cm²	0.285kg·cm²	0.283kg·cm²	0.283kg·cm²	0.283kg·cm²	0.281kg·cm²

* Scroll horizontally within the table area when the content is wide.

Specifications

Rated Input Speed	3000 rpm
Max Input Speed	6000 rpm
Max Radial Load	1420 N
Max Axial Load	1250 N
Noise	65 dB
Average Lifespan	20000 h
Standard Tolerance	- %
Lubricating	Synthetic oil lubrication
Weight	- kg
