Application of integrated servo motor in lifting robot

With the development of industrial automation and intelligent manufacturing, hanging intelligent inspection robots have gradually become an important role in many industrial scenarios. Such robots can not only improve work efficiency and reduce manual intervention, but also complete inspection tasks in complex or dangerous environments. In the design and manufacture of these robots, integrated stepper servo motors play a key role. Their high performance, high precision and high efficiency provide strong power support for the robots.

01.Equipment Introduction

The hanging intelligent inspection robot is an automated inspection device suitable for specific industrial environments. Its basic functions include autonomous navigation, high-definition video monitoring, environmental perception and data analysis, and it can monitor and record the status of the inspection area in real time.

A ceiling-mounted robot (picture from the Internet)

Suspended inspection robots are characterized by high precision, high efficiency and high safety. Their suspended design allows them to move flexibly in narrow spaces or complex environments, reducing the risks of manual inspections. At the same time, their sensors and algorithms can autonomously identify and judge abnormal situations, improving the accuracy and reliability of inspections.

Application of hanging intelligent inspection robot

The application of hanging intelligent inspection robots is very extensive, including power transmission lines, chemical plants, underground pipe corridors and other areas with complex environments and high risks. In these scenarios, it can effectively improve inspection efficiency, reduce labor costs, and ensure the safe and stable operation of facilities.

02.Solution

Taking a research institute’s suspended intelligent inspection robot equipment as an example, the equipment uses an integrated stepper servo motor as the drive and control core, and forms a closed-loop system with position sensors, controllers, etc.

The suspended intelligent inspection robot needs to move on tracks or ropes, and is usually equipped with various inspection tools, such as cameras, infrared sensors, etc. The integrated step servo motor as a walking drive device can accurately control the robot's moving speed and position, ensuring that the robot can reach the inspection point stably and accurately.

Example of scenario:

Motor model: STM57-M series

STM-The M series integrated stepper servo motor has precise position control, low operating noise, smooth movement, convenient operation, and can better achieve control accuracy requirements.

03.Advantages of integrated stepper servo motor

High integration improves the portability of equipment: The integrated stepper servo motor integrates functional modules such as stepper motor, servo driver, encoder and controller, which greatly reduces the size and weight of the equipment. At the same time, it simplifies system wiring and reduces potential failure points.

Flexibility to meet diverse needs: The integrated stepper servo motor supports CANopen/Modbus communication and can be flexibly controlled and adjusted as needed to adapt to different work requirements.

High-precision positioning improves measurement accuracy: The integrated stepper servo motor has high positioning accuracy and can achieve high-precision positioning of mobile equipment.

Multiple control modes: support PP, VM, PV, PT, HM, IP, CSP, CSV, CST standard modes; support NiMotion position mode, NiMotion speed mode, NiMotion torque mode.

High-speed response improves equipment efficiency: The integrated step servo motor has a fast response speed and can quickly adjust the angle and position of the detection equipment. This means that the detection unit can obtain sample information more quickly, improving the working efficiency and responsiveness of the equipment.

Complete alarm function: The integrated step servo motor can detect hardware failures in time to avoid affecting system operation. It is equipped with multiple safety protection functions. The LED flashing alarm can intuitively display the current status of the motor. It also has protection functions such as overvoltage/undervoltage, overheating, overcurrent, and stall alarm.
