AxisConfigurator Axis Configuration Software

AxisConfigurator is a dedicated axis configuration tool for NiMotion motion control systems. It provides a straightforward interface for setting up drive parameters, tuning servo performance, and configuring axis motion profiles. The software simplifies commissioning and optimization of single or multi-axis systems.

Product Details

AxisConfigurator Axis Configuration Software

In CODESYS, when using our self-developed motion control library for motor control, each axis group must be configured with parameters including communication type, network number, device number, gear ratio, homing mode settings, and I/O parameter mapping. A large number of axes significantly increases the workload. AxisConfigurator simplifies this process by generating configuration code that can be directly integrated into the user's program, greatly reducing programming effort.

Downloads

Name	Type	Size	Update Date	Download
NiMotion Software Selection Guide	Selection Guide	1.4MB	2026-08-25
