NIM_Math Mathematics Algorithm Library

A mathematics algorithm library by NiMotion, providing a comprehensive set of mathematical functions and algorithms for motion control and industrial automation applications, including vector operations, coordinate transformations, interpolation, and kinematic calculations.

Product Details

NIM_Math Mathematics Algorithm Library

In automation equipment, especially robot algorithm and program development, extensive mathematical operations are involved. However, standard compilers only include basic math functions such as sin, cos, tan, abs, and exp, which often cannot meet development requirements, requiring users to write custom functions. Since these functions are frequently used, and PLCopen-compliant library files offer good portability and reusability across general automation devices, they significantly reduce development workload and improve efficiency. NiMotion has developed math functions for robotics applications and encapsulated them into the NIM_Math library. Users can directly call the appropriate functions in their programs as needed.

Downloads

Name	Type	Size	Update Date	Download
NiMotion Software Selection Guide	Selection Guide	1.4MB	2026-08-25
