AxisGroupConfigurator Axis Group Robot Software

AxisGroupConfigurator is a configuration tool for multi-axis robot systems developed by NiMotion. It enables users to configure axis group parameters and generate corresponding code for simplified integration with motion control systems, streamlining the setup of coordinated multi-axis motion.

Product Details

AxisGroupConfigurator Axis Group Robot Software

When using our self-developed motion control library for axis group control, relevant parameters must be configured prior to use. These include the actual controlled axis group model type, structural parameters, directional kinematics model (end-effector tool type) parameters, the mapping relationship between individual motor axes and axis group joints, and the main task cycle. This software provides five axis group models and three tool models to streamline programming during axis group configuration. The code generated by this software can be directly integrated into the user's program. In programming, the code generated by the multi-axis configuration software must be used in conjunction with the code generated by the single-axis configuration software.

Downloads

Name	Type	Size	Update Date	Download
NiMotion Software Selection Guide	Selection Guide	1.4MB	2026-08-25
