NIMC301

NIMC301 Compact Motion Controller

Compact motion controller with built-in CANopen master station and PLC functions, supporting multiple programming languages.

Features

Ultra-compact size, USB powered
Supports CANopen master station
Compatible with ST, LD, SFC and FBD programming languages

Specifications

Appearance Dimensions	67.7×17.9×9.7mm
Mounting Method	USB plug-and-play
Power Requirements	USB powered (5VDC)
Processor	Cortex-M4 288MHz
Memory	4096KB
Flash Memory	368KB
USB Interface Speed	Full-speed 12Mbps
USB Interface Data Frame Interval	≥1ms
Number Of CAN Interfaces	1 (isolated)
CAN Interface Communication Rate	configurable 100Kbps~1Mbps, default 1Mbps
CAN Interface Galvanic Isolation	2500 Vrms@1min
CAN Interface Data Format	CANopen
CAN Interface Terminal Matching	Built-in 120Ω
Operating Temperature	0℃~+45℃
PLC Software	NIMCS2000 (NiMotion Self-developed PLC)
Instruction List IL	Not supported
Structured Text ST	Supported
Ladder Diagram LD	Supported
Sequential Function Chart SFC	Supported
Function Block Diagram FBD	Supported
Continuous Function Chart CFC	Not supported
Modbus RTU Master Slave	Only Modbus RTU slave
Modbus TCP Master Slave	Not supported
CANopen Master Slave	Only CANopen master
NiM_SML	Supported
USB Interface Transmission Capability	USB to dual RS232 channels

Product Details

Product Overview

The NIMC301 series motion controller is a miniature motion controller independently developed by NiMotion. It comes with a CANopen master station, has PLC control functions, and can also provide real-time expansion for the Windows platform. The size is only equivalent to the size of a "USB flash drive"!

Product Features

Multi-bus communication support

Supports CANopen, RS232 and USB communication, allowing quick connection to mainstream PLCs, motion controllers and host systems, with flexible networking and easy expansion.

Power requirements

Power supply: USB供电(5VDC), easy to source and quick to integrate into a system.

High-performance processing platform

Based on Cortex-M4 288MHz处理器，配置4096KB内存与368KB闪存, it delivers excellent data processing and real-time control capability for multi-axis coordination and complex logic operations.

Compact body design

Compact body of only 67.7×17.9×9.7mm can be installed close to the machine, saving valuable space in the control cabinet.

Power-off data retention

Supports power-loss data retention and an RTC real-time clock, so key parameters, operation records and time information are not lost when power is removed.

PLC control function

With PLC control function, logic and motion control development can be completed using standard PLC language, which is fast to start and easy to integrate

Downloads

Name	Type	Size	Update Date	Download
NiMotion Motion Controller Selection Guide	Selection Guide	26.6MB	2026-10-14
NIMC301 Controller User Manual	User Manual	5.6MB	2026-08-31
